Carbon Fiber Track Bike Frame 700C 48/51/54/56cm Carbon Road Bike Frameset Quick Release Frame Thru Axle 12x100mm/12x142mm Internal Routing((handlebar40x10cm),51cm)

Carbon Road Bike Framest – Lightweight, Stiff & High-PerformanceAerodynamic Design – Optimized tube shapes cut through wind for maximum efficiencyHidden internal routing: The frame with internal routing is simple and beautiful, with low wind resistance, and will not be affected by external forces on shifting and braking. The shifting cable is not easy to age.Frame name: Carbon fiber disc brake road frameMaterial: Carbon fiberSize: 48/51/54/56/58cmFork weight: 410g±15gHandlebar size: 380/400/420/440mmStem length: 90/100/110/120mmHead tube: 1-1/2" upper and lower large head tubeWeight: 1160g/54cmSeatpost weight: 225±10gSeat rail clamp: 7x7mm or 7x9mmBottom bracket specification: Press-fit BB86Maximum tire capacity: 700Cx28CBrake seat type: Disc brake (flat mount)Fork width: 12x100mmRear fork width: 12x142mmNotice:1. Please allow slight dimensional tolerances due to manual measurements, lighting in photography may cause color differences from real life.2. Please double check the size details in our list according to your actual situation to make sure you buy the right Bikes frame.

• 700C Road Bike Frameset: 48/51/54/56/58cm C Brake frame. Quick Release Frame F100mm R142mm, Max tires width 28C.
• Frame Specifications：For headset, Seatpost, Seatpost Clamp, Threaded bottom bracket. Full carbon fiber Tapered fork, weight 410g.
• Frames: Lightweight has good welding performance, so that the frame has a high strength and not easy to break characteristics. Flat weld patching, glossy baking paint.
• Internal Routing Bike Frame: Shifting brake and other control wires are hidden inside the frame to prevent wear and tear.
• Package：includes frame, fork, Headset,Seatpost Clamp, Wire Guide Plate.
