High Sensitivety 360 Degree 110V~220V AC Automatic Ceiling Infrared PIR Motion Sensor LED Light Switch 037 Nicely

InstructionThe Motion Sensor Switch adopts good sensitivity detector, integrated circuit. It gathers automatism, convenience, safety, saving-energy and practicality functions. The wide detection field is consisting of detectors. It works by receiving human motion infrared rays.When one enters the detection field, it can start the load at once and identify automatically day and night.Its installation is very convenient and its using is very wide. It has functions of power indication and the detection indication.SPECIFICATIONPower Source:110 -220V/AC Detection Range: 360° Power Frequency: 50Hz Working Temperature: -20°C~+40°C Ambient Light: 3-2000LUX (adjustable) <;93%RH Time-Delay: min: 10sec±3sec Max: 7min±2min Installation Height: 2.2-4m Power Consumption: 0.45W (work) 0.1W (static) Rated Load: 1200W (incandescent lamp) 300W (energy-saving lamp) Detection Motion Speed: 0.6 ~1.5m/s Detection Distance: 6m max (24°C)FUNCTION:1.Can identify day and night: The consumer can adjust work ambient light. It can work in the daytime and at night when it is adjusted on the "sun" position (max). It can work in the ambient light less than 3LUX when it is adjusted on the "moon" position (min). As for the adjustment pattern, please refer to the testing pattern.2.Time-Delay is added continually: When it receives the second induction signals after the first induction, it will compute time once more on the basic of the first time-delay rest.3.Time-Delay is adjustable. It can be set according to the consumer's desire. The minimum time is 10sec±3sec. The maximum is 7min±2min.INSTALLATION:(see the figure) 1.Switch off the power.2.Turn clockwise the bottom-stand and take off it. The power wire cross the hole in the middle of bottom-stand.3.The bottom-stand is fixed on the selected

• Features: PIR motion sensor switch
• Material: Plastic
• Item Type: Switches
• theory: PIR Infrared Motion sensor
